Sales Representative Welder & Copper Machinery
-
Certified Company Factory & Export
自动头式变压器面板散热器生产线
We supply Steel Drum Production Plants to manufacture standard Tight Head and Open Top steel drums with a production capacity of 100, 240, 360 or 600 drums per hour. The drum filling line also can be supplied by us.
The steel drums manufactured by our machines can be used contain Beverage, Chemical, Food, etc.
The maximum length of the panel | > 3,000 mm |
Minimum length of the panel | 500 mm |
The thickness of the assembled panel, flange to flange | 40 mm |
Cold rolled steel thickness | 1.0 - 1.2 mm |
Cold rolled steel width | 230 (231), 375 (377), or 520 (523)mm |
Operating Condition | 10 - 35 deg C, 10 - 85% RH |
Pneumatic Connection | 90 psi (6 bar) |
Hydraulic power pack | To suit customer requirements |
Pneumatics | SMC / Airtac |
Control | Mitsubishi |
Servo Systems | Mitsubishi |
Linear Bearings & Actuators | THK/Hiwin |
Electrical | Omron |
Fasteners | Metric, zinc plated |
- Superior panel design providing improved cooling characteristics and structural integrity
- The latest in machine control technology including proportionate pressure control for adjusting roll forming pressure (side to side)
